T1689 Technical Manual Rev 07 Specification
MV3000 Air Cooled DELTA Reactors, Inductors & Transformers
Page 67
2.13.9.3 31V5500/10 External Requirements
• If airflow is through the rear of the reactor module, care must be taken to ensure that the reactor
coils are not accessible through the rear of the cubicle as they expose high voltages. An
additional blanking plate is required in this instance to seal the underside air inlet aperture.
2.13.9.4 50Z0126/01 Sharing Reactor Features
• Designed for installation within the cubicle adjacent to the DELTA module..
• Able to be used as a transistor bridge sharing or output reactor, or as an input reactor for the
rectifier bridge (application and power rating dependant).
2.13.9.5 50Z0126/01 Interface
• Item width allows adjacent fitting at a pitch similar to the DELTA module.
• Electrical connections are by two sets of terminals, located at the front of the module
• The electrical connections are not polarity sensitive, meaning either set of terminals may be used
as input or output connections.
reactor
Table 2–34. – Sharing Reactor Details
2.13.9.6 Losses
Power loss = 3 x Iac² x R
reactor
Watts
Where R
reactor
is in ohms
Iac is in amperes.
