MXNET 1G USER MANUAL
10
USB 2
•
USB 2.0 Type A female connector port
• Supports routing USB 2.0 signals from the decoder to the designated host
encoder.
NOTE: Chipset V1 Decoders do not support High-speed USB connections. Chipset
V2 Decoders can support one isochronous connection to a High-speed USB device
(such as a microphone or digital camera).
11
USB SELECT
•
FPGA/MCU toggle switch
• Used for configuring the decoder for point-to-point connection with an
MXNet 1G encoder (default setting is MCU ISP)
12
USB
•
Micro-USB Type B female connector port
• Used for configuring the decoder for point-to-point connection with an
MXNet 1G encoder
13
1GbE NETWORK
•
8-pin RJ-45 female connector, 1000BASE-T copper Ethernet port
• Supports standard PoE power, IEEE 802.3AF (15.4 W)
• Maximum power consumption of 6.5 W
• 10/100/1000Mbps auto-negotiation
• MDI/MDI-X cable mode auto-negotiation
• Maximum distance 100m (330ft) over Cat5e and higher
14
BI DIR. O.M. LC
FIBER
•
Bidirectional SFP fiber optic connector port
• Supports single mode or multimode SFP modules for extremely long runs
• Recommended single mode fiber: LC to LC 1310nm, up to 40km (24.85 miles)
• Recommended multimode fiber: LC to LC 850nm, up to 550m (1804 feet)
15
HDMI OUT
•
19-pin HDMI Type A female connector port
• HDMI connection for endpoint device signal output
• Copy EDID functionality used in conjunction with front panel button press
16
AUDIO OUT
•
3.5mm stereo jack (TRS) audio output port
• De-embedded audio, extracts stereo analog audio
17
RESET
•
Recessed button, use a paperclip or pen to press in and hold for 7 seconds to
restore decoder to factory default settings
18
[Optional]
POWER
•
DC 12V/1A locking ring power charger to locally power decoder
• Not required when connecting decoder to a network switch that provides PoE
