© AXION TECHNOLOGIES LTD. INSTALLATION
2.2.4. OSCP COMMUNICATION CABLE
The OSCP communication cable connects the OSCP to the other communication networks of
the bus, if required. Figures in Section 6.4 OSCP CABLE show the different cable types that
can be used.
The PCOS communication cable connects as follows:
● Conner the first end of the OSCP power cable (15-pin connector) to the OSCP
OSCP2 connector. (See Figure 9)
● To connect to other communication networks, contact the Customer Service of Axion
Technologies Ltd., to get more information on specific connections.
User Manual (Revision A) Document No.: 3042145 Page 14
Figure 9: OSCP Communication Cable Connection
OSCP
FRONT SIGN RIGHT BACK PLATE
PLAQUE DE DROITE AFFICHEUR AVANT
CONTROL UNIT
UNITÉ DE CONTROLE
CONTROL CONSOL POWER CABLE
CÂBLE D' ALIM. AFF. CONSOLE DE COMMANDE
