Axion 40 Series - Edss Fuse Table; Table 5: Fuse Value According to Sign Model

© AXION TECHNOLOGIES LTD. REFERENCE TABLES
7.2. EDSS FUSE TABLE
Serial Number Value Type of Fuse
FRONT SIGN
FRONT 24 X 200 15 A Low Profile MINI
®
BLADE FUSE
FRONT 16 X 160 15 A Low Profile MINI
®
BLADE FUSE
CURB SIDE SIGN
SIDE 8 X 96 10 A Low Profile MINI
®
BLADE FUSE
SIDE 16 X 160 10 A Low Profile MINI
®
BLADE FUSE
SIDE 16 X 120 140 A Low Profile MINI
®
BLADE FUSE
SIDE 16 X 80 10 A Low Profile MINI
®
BLADE FUSE
SIDE 16 X 40 10 A Low Profile MINI
®
BLADE FUSE
REAR SIGN
REAR 16 X 48 10 A Low Profile MINI
®
BLADE FUSE
REAR 16 X 40 10 A Low Profile MINI
®
BLADE FUSE
KEY NUMBER SIGN
KEY NUMBER 16 X 40 10 A Low Profile MINI
®
BLADE FUSE
CONTROL CONSOLE / OSCP
All signs 2 A Low Profile MINI
®
BLADE FUSE
Table 5: Fuse Value According to Sign Model
NOTE: All fuses used are fast blow type.
User Manual (Revision A) Document No.: 3042145 Page 76
