Axion 40 Series - 6.4.3. COMMUNICATION CABLE WITH J1708 AND RS-232

© AXION TECHNOLOGIES LTD. DRAWINGS
6.3.3. CABLE WITH INVERTER AND YIELD AND WITH J1708 AND RS-232
CONNECTION
User Manual (Revision A) Document No.: 3042145 Page 66
Figure 46: Cable with Inverter and Yield and with J1708 and RS-232
Connection
