5. Select CoS1
CoS1 CoS1
CoS1 in Class of Service
Class of ServiceClass of Service
Class of Service and enter 22
2222
22 in Type of Service
Type of ServiceType of Service
Type of Service (ToS). Any incoming
packet from LAN Group 1 (layer 3) with a ToS of 22 is mapped to CoS1, the
highest priority, which is normally given to the voice packets.
6. Leave the default value CoS1 in Default Non-IP. Any incoming packet from LAN
Group 1 without an IP is mapped to CoS1, the highest priority.
7. Click Apply
ApplyApply
Apply to temporarily activate the settings.
8. Repeat step 5-7 to add more rules to LAN Group 1. Up to 255 rules can be
configured for each interface.
9. To make changes permanent, click Save Settings
Save SettingsSave Settings
Save Settings.
Notes:
Notes:Notes:
Notes:
Any priority bits that have not been mapped to a CoS default to CoS6, the lowest
priority.
Any WAN interface that is not configured has the default Untrusted mode.
