R5905754 /13 DPxK-32B 107
SMPTE Standard
Source
Resolution
Frame Rate
Display Rate Scan Type
SMPTE 296M 1280 x 720 23.976
24
25
29.970
30
50
59.940
60
23.976
24
25
29.970
30
50
59.940
60
Progressive
Y Cb Cr 4:4:4 10-Bit
RGB (XYZ) 4:4:4 10-Bit
SMPTE 274M
4
1920 x 1080 50
59.940
60
50
59.940
60
Progressive
Y Cb Cr 4:2:2 10-Bit
SMPTE 274M 1920 x 1080 23.976
24
25
29.97
30
23.976
24
25
29.97
30
Progressive
Y Cb Cr 4:2:2 12-Bit only
Y Cb Cr 4:4:4 10 or 12-Bit
RGB (XYZ) 4:4:4 10 or 12-Bit
SMPTE 274M 1920 x 1080 50
59.940
60
50
59.940
60
Interlaced
Y Cb Cr 4:2:2 12-Bit only
Y Cb Cr 4:4:4 10 or 12-Bit
RGB (XYZ) 4:4:4 10 or 12-Bit
SMPTE 428-9 2048 x 1080 23.976
24
23.976
24
Progressive
Y Cb Cr 4:4:4 12-Bit
RGB (XYZ) 4:4:4 12-Bit
Dual Stream 3G HD-SDI (SMPTE 425) formats
SMPTE Standard
Source
Resolution
Frame Rate
Display Rate Scan Type
SMPTE 292M
SMPTE 428-9
1920 x 1080
2048 x 1080
23.976
24
25
29.970
30
47.952
48
50
59.940
60
Progressive
Y Cb Cr 4:2:2 10-Bit
7.7 ICMP HDMI 2.0 specifications
HDMI
HDMI (High-Definition Multimedia Interface) is a compact audio/video interface for transferring
uncompressed video data and compressed/uncompressed digital audio data from a HDMI-
compliant device ("the source device") to a compatible computer monitor, video projector, digital
television, or digital audio device. HDMI is a digital replacement for existing analog video standards.
HDMI 2.0 specifications
HDMI
Both HDMI 2.0 inputs are fully compliant with the HDMI 1.4, 1.4a, 1.4b, 2.0 and 2.0a revisions of the HDMI
specification.
ICMP
4: only supported in 3G level A mapping, others formats are supported in both level A and level B mapping.
