R5905754 /13 DPxK-32B 17
UPS requirements
The Uninterruptible Power Supply (UPS), also known as a Continuous Power Supply (CPS), must have an
output voltage of 200-240V at 50-60Hz and must be capable of delivering an output current of 5,5 amperes.
This UPS provides only power for the electronics and not for the lamp.
The connection between the UPS unit and the UPS inlet of the projector must be done with a certified AC
power supply cord of minimum 0,75 mm² or 18 AWG and minimum 300V.
CAUTION: The 200–240V power outlet (UPS OUTLET) of the projector may not be used to provide
the UPS unit with power! The UPS OUTLET of the projector may only be used for connection to the
UPS INLET of the projector.
The DPxK-32B does not have a built in UPS unit.
Exhaust outlet for external fan
The exhaust outlet has an output voltage of 200–240V at 50–60 Hz; switched and maximum 3 amperes is
allowed.
The connection between the exhaust outlet and the external blower must be done with a certified AC power
supply cord of minimum 0,75 mm² or 18 AWG and minimum 300V.
CAUTION: The 200–240V power outlet (exhaust outlet) of the projector may not be used to provide
power to any other device than an external exhaust fan. Maximum allowed current : 3A.
Projector weight
Do not underestimate the weight of the Barco DPxK-32B. The projector weights about ±140 kg (±309 lb.)
without lens. Be sure that the pedestal on which the projector has to be installed is capable of handling five (5)
times the complete load of the system.
Barco offers a pedestal for the DPxK-32B. This universal pedestal allows a solid and easy setup of
the projector. The universal pedestal has a separate compartment to install the UPS unit for the
DPxK-32B. Futhermore, the universal pedestal contains a standard 19” rack to build in the projector
peripherals such as alternative content switchers.
2.2 Unpacking the projector
What has to be done ?
Upon delivery, the projector is packed in a carton box upon a wooden pallet and secured with banding and
fastening clips. Furthermore, to provide protection during transportation, the projector is surrounded with
foam. Once the projector has arrived at the installation site, it needs to be removed from the carton box and
wooden pallet in a safe manner without damaging the projector.
After unpacking let the projector acclimatises to a room temperature higher then 10°C (50°F) and
lower then 35°C (95°F). Neglecting this may result in a start up failure of the Light Processor Unit.
How to unpack
1. Loosen the banding by pulling the free end of the banding loop in the clip.
Take off the box cover.
