General settings Advanced settings
Source Port Port type Mode Scan type Color
space
Pixel mapping Calibration
HD-SDI - 4K 4:2:2 10
bits/color
Progressive YCbCr HD-SDI - Quad
Link
Single
Progressive SF -
1st field dominant
YCbCr HD-SDI - Quad
Link
Single
Progressive SF -
2nd field
dominant
YCbCr HD-SDI - Quad
Link
Single
6.6 Integrated Media Block/Server (optional)
Not available for purchase at Barco for use in Taiwanese market.
Depending on the projector configuration the projector card cage is either equipped with an ICP or
ICMP. In case an ICP is installed then an IMB, IMS, or HDSDI input module can be optionally
inserted into the slot below the ICP. This is not the case if the ICMP is installed. For more
information about the ICMP see chapter called ICMP.
Integrated Media Block (IMB)
Image 6-7: Example of IMB powered by Doremi.
Integrated Media Server (IMS)
Image 6-8: Example of IMS powered by Doremi.
Configuration and operation instructions for IMB and IMS are not included in this document. See
manufacturers website of the installed IMB/IMS for technical documentation and support.
