R5905754 /13 DPxK-32B164
A.1 Specifications of the DP2K-32B
Overview
Digital MicroMirror Device™ 3 x 1.2” DC2K dark metal devices
Native resolution 2,048 x 1,080 pixels
Housing Hermetically sealed DMDs and optical assembly
Lamp 3kW - 7kW
Light output 33,000 lumens
Screen size Up to 32m / 105ft wide
Contrast ratio 2,000:1
Digital Video Inputs 2 x DVI input
both selectable as single and dual link
Integrated Media Server
(IMS)
JPEG2000 2K & 4K DCI play-out
High Frame Rates 3D up to 120fps (60fps per eye)
JPEG 2000 bit-rates up to 500Mbps
Dolby3D color-correction
MPEG-2
H.264
2 x 3G-SDI inputs
1x HDMI 1.4a input (BluRay 3D / 4K)
16x AES/EBU audio channels (2x RJ45)
4x GPI, 6x GPO (2x RJ45)
2x ETH for management & ingest
3x front-accessible USB for ingest
1x eSATA port for fast ingest
SMS software (IMS) Show player/editor/scheduler
Automation, 3D, ingest
TMS integration
Prime lenses 1.25 - 1.45
1.45 - 2.05
1.6 - 2.35
1.8 - 2.8
2.15 - 3.6
2.8 - 5.5
Projector diagnostics via Communicator control software
via SNMP agent
Power requirements 3x 400V + N or 3x220V
30,000 BTU/hr (with 6.5 kw lamp)
Projector dimensions
(HxWxD)
604 x 754 x 1129 mm
23.78 x 29.69 x 44.45 inch
NB: min. 5 cm of air inlet spacing required at the bottom of projector
Projector weight 140 kg (309 lbs)
