Source: 2K
General settings Advanced settings
Port Port type Mode Scan type Color
space
Pixel mapping Calibration
3G-level B-Dual
link
4:4:4 12
bits/color
Progressive XYZ/
RGB
3G-level A-Single
link
3G-level B-Dual
link
A+B HDSDI
Duallink AB
4:4:4 10
bits/color
Progressive RGB HDSDI-Dual link Single
Progressive - field
bit normal
Progressive - field
bit inverted
Progressive SF -
2nd field dominant
Progressive SF-
1st field dominant
4:4:4 12
bits/color
Progressive XYZ/
RGB
Progressive - field
bit normal
Progressive - field
bit inverted
Progressive SF-
2nd field dominant
Progressive SF-
1st field dominant
Source: 2K-3D
General settings Advanced settings
Port Port type Mode Scan type Color
space
Pixel mapping Calibration
A or
B
3GSDI link -
3D
4:2:2 10
bits/color
Progressive YCbCr 3G - Level B - Dual
stream
Single
Dual
(separate left
/ right eye)
Progressive SF-
1st field dominant
YCbCr 3G - Level B - Dual
stream
Single
Dual
(separate left
/ right eye)
Progressive SF -
2nd field dominant
YCbCr 3G - Level B - Dual
stream
Single
Dual
(separate left
/ right eye)
A+B HDSDI 3D 4:2:2 10
bits/color
Progressive YCbCr HDSDI -
Interleaved
Single
Dual
(separate left
/ right eye)
