R5905754 /13 DPxK-32B 85
When using all 4 four inputs to create the image connect the quadrants of the image to the inputs as indicated
on the drawing.
A B
DC
Image 6-6: Quadrant connection
To configure the input, consult the Communicator manual
Source formats
General settings Advanced settings
Source Port Port type Mode Scan type Color
space
Pixel mapping Calibration
2K A or
B
HD-SDI
Single link
4:2:2 10
bits/color
Progressive YCbCr HD-SDI-Single
link
Single
Progressive -
field bit normal
Progressive -
field bit inverted
Progressive SF -
2nd field
dominant
Progressive SF -
1st field dominant
3G-SDI link 4:2:2 12
bits/color
Progressive YCbCr 3G-level A-Single
link
Single
3G-level B-Dual
link
4:4:4 10
bits/color
Progressive RGB 3G-level A-Single
link
3G-level B-Dual
link
4:4:4 12
bits/color
Progressive XYZ/
RGB
3G-level A-Single
link
3G-level B-Dual
link
A+B HD-SDI
Duallink AB
4:4:4 10
bits/color
Progressive RGB HD-SDI-Dual link Single
Input & communication
