DVI Input formats
Input
Source
standard
Vertical rate
Scan type Color space Sampling Color depth
Single DVI VESA
(640x480)
60 Progressive RGB 4:4:4 8 bit
Single DVI VESA
(640x480)
72 Progressive RGB 4:4:4 8 bit
Single DVI VESA
(800x600)
60 Progressive RGB 4:4:4 8 bit
Single DVI VESA
(800x600)
72 Progressive RGB 4:4:4 8 bit
Single DVI VESA
(1024x768)
60 Progressive RGB 4:4:4 8 bit
Single DVI VESA
(1024x768)
70 Progressive RGB 4:4:4 8 bit
Single DVI VESA
(1280x1024)
60 Progressive RGB 4:4:4 8 bit
Single DVI 1280x720 60 Progressive RGB 4:4:4 8 bit
Single DVI 1920x1080 60 Progressive RGB 4:4:4 8 bit
Single DVI 2048x1080 50/60 Progressive RGB 4:4:4 8 bit
Single DVI 1920x1080i 50/60 Interlaced RGB 4:4:4 8 bit
Twin DVI ACS
(2048x1080)
50/59.94 Progressive RGB 4:4:4 10 bit
Twin DVI ACS
(2048x1080)
50/59.94 Progressive RGB 4:4:4 12 bit
DVI-3D 3D
(2048x1080)
24/eye Progressive RGB 4:4:4 2x8 bit
DVI-3D 3D
(2048x1080)
25/eye Progressive RGB 4:4:4 2x8 bit
DVI-3D 3D
(2048x1080)
30/eye Progressive RGB 4:4:4 2x8 bit
DVI-3D 3D
(2048x1080)
50/eye Progressive RGB 4:4:4 2x8 bit
About DVI-4K:
Two columns of 2048x2160 are needed, where DVI-A is left image and DVI-B is right image. Use Rec 709 for
4K as PFC file.
2048
2160
DVI-A
8 bit
24 Hz
2048
2160
DVI-B
8 bit
24 Hz
Image 6-11: DVI-4K
