19. Start Pulse Generator
SS
S
Image 19-4
Loosen SPG fi xa tion
4. Remove the Start Pulse Generator from the projector.
Caution: Do not damage the ferrite blocks while removing the SP G module.
Note: The ferrite blocks ha ve to be reu sed upon the SPG module which you want to install.
Image 19-5
Remove SP G
R5905043 DP2K-12C/11CX 19/02/2018 307
