Barco DP2K-12C

20. Fan replacement procedure
5. Take out the fan.
6. Insert a new fan, with the arrow indication on the fan pointing to the inner side of the projector.
7. Driveinthe4fixation screws.
8. Reconnect the fan power cable. Us e a cable tie to s ecure th e c ables.
R5905043 DP2K-12C/11CX 19/02/2018
313
