Appendix F: Special Order Configurations 167
6-Blue 0-Violet 0-UV 3-Red Configuration
6-Blue 0-Violet 0-UV 3-Red supports a blue octagon, and a red trigon. Table F-1
shows the detectors, filters, and mirrors used in the default configuration. The
word “blank” indicates that a blank optical holder should be used instead of a
mirror or filter. A dash (—) indicates that no slot exists for a mirror in that PMT
position.
The 6-Blue 0-Violet 0-UV 3-Red maps are:
• 6-Color Blue Octagon Default Configuration Map on page 181
• 3-Color Red Trigon Default Configuration Map on page 185
Table F-1 6-Blue 0-Violet 0-UV 3-Red default mirror and filter configuration
Detector Array
(Laser)
PMT
(Detector)
Longpass
Dichroic
Mirror
Bandpass
Filter
Fluorochrome or
Scatter Parameter
blue octagon
(488-nm laser)
A 755 LP 780/60 PE-Cy7
B 685 LP 695/40 PerCP-Cy5.5
C 655 LP 660/20 PE-Cy5
D 600 LP 610/20 PE-Texas Red™
E 550 LP 575/26 PE
F 505 LP 530/30 FITC, Alexa Fluor® 488
G blank 488/10 SSC
H — blank none
red trigon
(633-nm laser)
A 755 LP 780/60 APC-Cy7
B 710 LP 730/45 Alexa Fluor® 700
C — 660/20 APC
