178 BD LSR II User’s Guide
6-Blue 6-Violet 2-UV 4-Red Configuration
6-Blue 6-Violet 2-UV 4-Red supports blue, violet, and red octagons, and a UV
trigon. Table F-8 shows the detectors, filters, and mirrors used in the default
configuration. The word “blank” indicates that a blank optical holder should be
used instead of a mirror or filter. A dash (—) indicates that no slot exists for a
mirror in that PMT position.
The 6-Blue 6-Violet 2-UV 4-Red maps are:
• 6-Color Blue Octagon Default Configuration Map on page 181
• 6-Color Violet Octagon Default Configuration Map on page 183
• 2-Color UV Trigon Default Configuration Map on page 184
• 4-Color Red Octagon Default Configuration Map on page 186
Table F-8 6-Blue 6-Violet 2-UV 4-Red default mirror and filter configuration
Detector Array
(Laser)
PMT
(Detector)
Longpass
Dichroic
Mirror
Bandpass
Filter
Fluorochrome or
Scatter Parameter
blue octagon
(488-nm laser)
A 755 LP 780/60 PE-Cy7
B 685 LP 695/40 PerCP-Cy5.5
C 655 LP 660/20 PE-Cy5
D 600 LP 610/20 PE-Texas Red™
E 550 LP 575/26 PE
F 505 LP 530/30 FITC, Alexa Fluor® 488
G blank 488/10 SSC
H — blank none
