Chapter 1: Introduction 27
Control Panel
The control panel contains fluidics controls (Figure 1-2). For a description of the
controls, see:
• Sample Flow Rate Control on page 28
• Fluid Control on page 28
Figure 1-2 Control panel
Handles
The instrument handles (Figure 1-1 on page 26) are for BD Biosciences
authorized personnel only. Do not access them or attempt to lift the
instrument with them, or you could injure yourself.
LO MED HI
RUN
STNDBY
PRIME
sample flow rate
fluid control buttons
SAMPLE
FINE ADJ
control buttons
