Appendix F: Special Order Configurations 173
Table F-5 6-Blue 6-Violet 0-UV 3-Red default mirror and filter configuration
Detector Array
(Laser)
PMT
(Detector)
Longpass
Dichroic
Mirror
Bandpass
Filter
Fluorochrome or
Scatter Parameter
blue octagon
(488-nm laser)
A 755 LP 780/60 PE-Cy7
B 685 LP 695/40 PerCP-Cy5.5
C 655 LP 660/20 PE-Cy5
D 600 LP 610/20 PE-Texas Red™
E 550 LP 575/26 PE
F 505 LP 530/30 FITC, Alexa Fluor® 488
G blank 488/10 SSC
H — blank none
violet octagon
(405-nm laser)
A 630 LP 655/8 Qdot 655
B 595 LP 605/12 Qdot 605
C 575 LP 585/15 Qdot 585
D 545 LP 560/20 Qdot 565
E 475 LP 525/50 AmCyan, Qdot 525
F blank 450/50 Pacific Blue™
G blank blank none
H — blank none
red trigon
(633-nm laser)
A 755 LP 780/60 APC-Cy7
B 710 LP 730/45 Alexa Fluor® 700
C — 660/20 APC
