BD LSR II - Page 175

Appendix F: Special Order Configurations 175
violet octagon
(405-nm laser)
A 630 LP 655/8 Qdot 655
B 595 LP 605/12 Qdot 605
C 575 LP 585/15 Qdot 585
D 545 LP 560/20 Qdot 565
E 475 LP 525/50 AmCyan, Qdot 525
F blank 450/50 Pacific Blue™
G blank blank none
H — blank none
red octagon
(633-nm laser)
A 755 LP 780/60 APC-Cy7
B 710 LP 730/45 Alexa Fluor® 700
C 675 LP 685/35 Alexa Fluor® 680
D — 660/20 APC
E blank blank none
F blank blank none
G blank blank none
H — blank none
Table F-6 6-Blue 6-Violet 0-UV 4-Red default mirror and filter configuration (continued)
Detector Array
(Laser)
PMT
(Detector)
Longpass
Dichroic
Mirror
Bandpass
Filter
Fluorochrome or
Scatter Parameter
