4-27
TotalAlert Innity™ HTM Medical Gas Notication System
4107 9016 60.01
Figure 92: Gas Text Screen
Figure 93: Area Monitored
Figure 94: [Units of Measure] Tab
Figure 95: Low Alarm Settings Tab
C = [Gas Name] Tab
1. Touch the Erase button on the keyboard to delete
the gas name.
2. Enter the new gas name. Touch the [<ÁÑ] to toggle
to symbols. Touch the [1AZ] key to toggle back to
letters and numbers.
3. Touch the Save button.
D = Area Monitored Tab
To add locations to be monitored:
1. Touch an unused location tab.
2. Using the keyboard, enter the name of the location
that you would like to monitor (e.g., ROOM 1). Enter
multiple locations as needed (e.g., Room 1, Room 2,
Room 5).
3. Touch the Save button. A check appears when the
location is saved.
Note: To edit the location information, touch the Pencil
button.
E = [Units Of Measure] Tab
To change the unit of measure:
1. Touch the tab for the appropriate unit of measure.
2. Touch the Save button to close the screen
F = Low Alarm Settings Tab
• Low Alarm Set Point
You can remove the low alarm set point or customize
the low alarm set point.
To remove the low alarm set point:
1. Touch the NONE tab.
2. Touch the check on the CONFIRM SETTINGS
CHANGE screen.
To customize the low alarm set point:
1. Touch the ADJUST tab.
2. Enter the new set point.
3. Touch the Save button.
