Diagmessages of module AxisMain

Multi axis servo system - AX8000128

Version: 1.1

6.29 6396, additional Factor Group Parameters: Feed

constant illegal feed

The actual combination of the factor group Parameters is not allowed for this Device.

Diagnostic Code (Hex.) Diagnostic Code (Dez.)

6396 25494

Class Type

Error Error

Standard Reaction Reset

Axis is inoperable Execute Reset-Command (Fault reset).

Possible Causes Solutions

The additional feed constant - feed contains an illegal

value (Object 0x60E9/1 ChA or 0x68E9/1 ChB).

Please use a 2

value (x from 16 to 28) for rotary

encoders and a 10

value (x from 0 to 9) for linear

encoders.

Internal: 0x6396, additional Factor Group Parameters: Feed constant illegal feed
