Standard-Messages

Multi axis servo system - AX800068

Version: 1.1

3.54 A031, DynPdo Mapping Warning: Unable to map Object

(not possible).

Diagnostic Code (Hex.) Diagnostic Code (Dez.)

A031 41009

Class Type

Warning Warning

Standard Reaction Reset

No Warning: No reset required.

Possible Causes Solutions

A mapping Parameter is not supported of this Device. Please check, your mapping Configuration.

Internal: 0xA031, DynPdo Mapping Warning: Unable to map Object 0x%x/%x.(not possible) (SyncManager

%u)

Default Chapter3
- Table of Contents3
1 Notes on the Documentation9
2 Introduction to the Diagnostic System10
- Basic Knowledge of the Diagnostic System10
- Settings with Respect to the Diagnostic System14
3 Standard-Messages15
- 0000, no Error15
- 5190, Test 5V Supply Failed16
- 5580, Read Failure EEPROM17
- 5581, Checksum Failure EEPROM18
- 5582, EEPROM Contains Blank Data19
- 5583, Unexpected EEPROM20
- 5584, EEPROM Contains Blank Data21
- 5585, Unexpected EEPROM22
- 5586, Restored Errormessages from Persistent Memory23
- 5590, Detected Incompatible Pcb24
- 5591, Identity Incompatible to a Pcb25
- 5592, Firmwareindex Is Incompatible to this Firmware26
- 5593, Structure Version Is Incompatible to this Firmware27
- 5594, Simulating Persistent Data Features28
- 5596, Storing of Persistent Data Failed29
- 5597, Unsupported Prototype Hardware30
- 5598, Identity Incompatible to Device31
- 5599, Identity Incompatible to a Device32
- 6180, Internal Software Error Type a33
- 6181, Internal Software Error Type B34
- 6182, Internal Software Error Type C35
- 6190, Init Timeout36
- 6382, Illegal Slotconfiguration. Slot Is Empty37
- 6383, Illegal Slotconfiguration. Double Feedback Selection38
- 6384, Illegal Slotconfiguration. Slot Has to be Empty39
- 63B0, Transition Pre-Op to Safe-Op (Ecat) Not Successful40
- 63B1, Transition Safe-Op to Op (Ecat) Not Successful41
- 63B2, Transition Op to Safe-Op (Ecat) Not Successful42
- 63B3, Transition Safe-Op to Pre-Op (Ecat) Not Successful43
- 8180, System Restart or Sync Lost44
- 8181, Lost Distributed Clocks Sync45
- A000, Transition Pre-Op to Safe-Op Not Successful. Sync Manager Length Error46
- A001, Transition Pre-Op to Safe-Op Not Successful. Sync Manager Address Error47
- A002, Transition Pre-Op to Safe-Op Not Successful. Sync Manager Settings Error48
- A003, Transition Pre-Op to Safe-Op Not Successful. Sync Manager Address Range Overlap49
- A004, Sync Manager Is Disabled and Has a Size Unequal Zero50
- A005, Sync Manager Address Is Not Multiple of 451
- A00B, Dynamic Sync Manager Address Is Not Multiple of 452
- A00C, Dynamic Sync Manager Address Range Overlap53
- A00D, Dynamic Sync Manager Settings Error54
- A00E, Dynamic Sync Manager Address Error55
- A00F, Dynamic Sync Manager Length Error56
- A010, SDO Complete Access Error57
- A011, Pdo Mapping Error: Unable to Map Object (Not Possible)58
- A013, Pdo Mapping Error: Double Mapping of Object59
- A015, Pdo Mapping Error: Unable to Map Object (no Mappings Left)60
- A017, Pdo Mapping Error: Object Has to be Mapped Always61
- A019, Pdo Mapping Error: Object Has to be Mapped Because of Modes of Operation62
- A01B, Pdo Bitmapping Error: Object a Is Not Next to Object B63
- A01D, Pdo Bitmapping Error: Can Not Transform Bit-Mappings to Byte-Mappings64
- A01F, Pdo Mapping Error: Invalid Oversampling Factor65
- A021, Pdo Mapping Error: Oversampling Is Not Allowed66
- A023, Pdo Assignment Error67
- A031, Dynpdo Mapping Warning: Unable to Map Object (Not Possible)68
- A033, Dynpdo Mapping Warning: Double Mapping of Object69
- A035, Dynpdo Mapping Warning: Unable to Map Object (no Mappings Left)70
- A037, Dynpdo Mapping Warning: Object Has to be Mapped Always71
- A039, Dynpdo Mapping Warning: Object Has to be Mapped Because of Modes of Operation72
- A03B, Dynpdo Bitmapping Warning: Object a Is Not Next to Object B73
- A03D, Dynpdo Bitmapping Warning: Can Not Transform Bit-Mappings to Byte-Mappings74
- A03F, Dynpdo Mapping Warning: Invalid Oversampling Factor75
- A041, Dynpdo Mapping Warning: Oversampling Is Not Allowed76
- A043, Dynpdo Assignment Warning77
- A080, Safe-Op Is Not Possible Because the Local Twincat Runtime Is in Configmode78
- A081, Transition Pre-Op to Safe-Op Not Successful. Safetycard Not Detected79
- A082, Ethercat Slave Stack Error80
- FFFD, Debug Firmware, Replace "As Soon as Possible81
- FFFF, Internal Error, Additional Errorcode82
