Diagmessages of module TorqueControl

Multi axis servo system - AX8000 185

Version: 1.1

12 Diagmessages of module TorqueControl

12.1 2330, Earth leakage (motor-side)

The Iuvw sum Monitoring detected an Error.

Diagnostic Code (Hex.) Diagnostic Code (Dez.)

2330 9008

Class Type

Error Motor connection error

Standard Reaction Reset

Closed loop ramp Execute Reset-Command (Fault reset).

Possible Causes Solutions

Iuvw sum (0x3242/14) raised above the parameter

Iuvw sum max (0x3243/07)

Please check the Motor connection and validate the

parameter value.

Internal: 0x2330, Earth leakage (motor-side)
