Diagmessages of module DeviceMain

Multi axis servo system - AX800090

Version: 1.1

4.8 5186, Power supply controlword, regenerative brake

order

The power supply device is in an error state and sent a regenerative brake order to the connected Axes.

Diagnostic Code (Hex.) Diagnostic Code (Dez.)

5186 20870

Class Type

Error Error

Standard Reaction Reset

Closed loop ramp Execute Reset-Command (Fault reset).

Possible Causes Solutions

Something went wrong in the power supply device. Please check the messages of the power supply

device.

Internal: 0x5186, Power supply controlword, regenerative brake order

Default Chapter3
