Diagmessages of module AxisMain

Multi axis servo system - AX8000154

Version: 1.1

6.55 8183, Controlword output cycle counter monitoring

The output cycle counter of the controlword didn't increment for at least two cycles and the monitoring

function is activated.

Diagnostic Code (Hex.) Diagnostic Code (Dez.)

8183 33155

Class Type

Error Error

Standard Reaction Reset

Closed loop ramp Execute Reset-Command (Fault reset).

Possible Causes Solutions

The Output cycle counter monitoring is enabled and

detected an error.

Check if the output cycle counter function is enabled

in your NC. Check your EtherCAT realtime status.

Internal: 0x8183, Controlword output cycle counter monitoring
