Standard-Messages

Multi axis servo system - AX8000 25

Version: 1.1

3.11 5591, Identity incompatible to a Pcb

Detected incompatible Pcb for this ESC EEPROM.

- ID 0: ControlPcb

- ID 1: FrontPcb

- ID 2: AdditionalAxisPcb

- ID 3: DisplayPcb

- ID 6: SafetyPcb

- ID 7: CpuPcb

Diagnostic Code (Hex.) Diagnostic Code (Dez.)

5591 21905

Class Type

Error Error

Standard Reaction Reset

Torque off A reset is not possible. The drive detected a fatal

hard- or software error.

Possible Causes Solutions

You might have updated the ESC EEPROM with the

wrong Identity.

Perform an EEPROM Update with the

Systemmanager.

Internal: 0x5591, ESC EEPROM Identity is incompatible to Pcb ID %u.
