1 695 600 968 2019-01-28| Beissbarth GmbH
Product description | MT ZERO 6 LCD | 79 en
Item Denomination Function
1 Wheel guard R Protecting the operator from ejected objects (e.g. dirt, water).
R Starting and stopping measurement.
2 Sonar probe R Determines the rim width by means of the probe.
R Laser beam for indicating where to attach the clip-on balance weight on the
outside of the wheel.
3 Rim-distance gauge (electronic) R Records rim distance and rim diameter.
R Determines the positions for attaching the adhesive balance weights.
4 Cone of drive shaft Flange mount
5 Laser If the Easyfix® function is switched off, the position of the adhesive balance
weights is indicated by a laser beam as soon as the correct balancing position is
reached
Lighting Always switched on whenever the electronic rim-distance gauge is in use.
6 Pedal MT ZERO 6 LCD AWx
Locking the shaft/wheel
MT ZERO 6 LCD AWxP
Pedal up
Pedal down
Locking/releasing the pneumatic flange
Locking the shaft/wheel
7 Digital control panel Command interface for use of the wheel balancing machine.
8 Shelf R Storage of cones and tools.
R Shelf for balance weights and accessories.
9 Mains socket Connection for power supply cable.
10 On/off switch Switching the wheel balancing machine on and off.
11 Interface card Internal interface card for connecting the measurement system.
12 Quick-locking nut MT ZERO 6 LCD AWx: centering and securing the wheel on the cone
13 Centering flange MT ZERO 6 LCD AWx: centering and securing the wheel on the cone
14 Securing cone Centering the wheel on the flange shaft.
15 Clamping tool holder Storing accessories
16 Oiler regulator filter unit for processing
the compressed air with pneumatic
connection
MT ZERO 6 LCD AWxP:
R Checking/setting the operating pressure
R Removing dirt
R Supplying oil to compressed-air system
17 Spacer plate MT ZERO 6 LCD AWxP: centering and securing the wheel on the cone.
18 Centering flange with tie rod MT ZERO 6 LCD AWxP: centering and securing the wheel on the cone
19 Weight positioning gauge Manual measurement of the width and positioning of the adhesive balance
weights with the programs ALU2, ALU3, adhesive balance weight statics, PAX2.
20 Balance weight holder Removing the wheel weights from the rim.
21 Measuring compass Manual measurement of rim width and rim diameter.
22 Concave socket For use with quick-locking nut with outside cone attachment.
23 Spacer ring Used in combination with the quick-locking nut to secure the wheels if a cone is
used on the flange.
24 Rubber cap For protective purposes when clamping aluminum rims.
25 Plastic spatula For removing adhesive balance weights
26 USB port For updating the software.
27 Connector plate For protecting the connections used to connect the digital control panel
