Beissbarth MT ZERO 6 LCD - 14. Technical Data; Mt Zero 6 Lcd; Temperatures; Working Range

1 695 600 968 2019-01-28| Beissbarth GmbH
Technical data | MT ZERO 6 LCD | 127 en
14.4 Dimensions and weights
Function Specifications
X x Y x Z max 1400 x 1840 x 1300 mm
Net weight 160 kg
Z
651127-58_BM
X
Y
651127-59_BM
14. Technical data
14.1 MT ZERO 6 LCD
Function Specifications
Shaft rotational speed 220 U/min 50 Hz
Corrective measure 1 g (0.05 oz)
Supply 230 V 1~ (50/60 Hz)
Power input 0.7 kW
MT ZERO 6 LCD AWxP compressed-
air supply
8 – 10 bar
Degree of protection IP 22
14.2 Temperatures
Function Specifications
Working temperature +5° C \ +40° C
Storage Temperature -20° C \ + 60° C
Temperature gradient 20° C
Relative operating humidity (25°C, 24
hours)
10% \ 90% (40° C)
Relative humidity gradient 10%
Installation height -200 mt. \ 3.000 mt.
Transportation height -200 mt. \ 12.000 mt.
14.3 Working range
Function min / max
Rim width, adjustable by keys 1'' - 20''
Rim width, measuring range of
electronic rim-distance gauge / rim
width gauge
1'' - 15''
Rim diameter, adjustable by keys 8'' - 40''
Rim diameter, measuring range of
electronic rim-distance gauge
10'' - 30''
Maximum wheel weight 80 kg
Maximum wheel diameter 1150 mm
Maximum wheel width 490 mm
Average measuring time 6 sec
