114 | MT ZERO 6 LCD | Menu navigation
10. Menu navigation
10.1 Menu access
¶ Press the <MENU> key.
 The first menu level will be called up.
i Access to the menus is allowed only from the basic
machine screen. The "OPT" and "SPLIT" functions
cannot be opened directly.
To navigate, follow the instructions in the table.
Key Function
Scrolling through the options
R Access to the submenus.
R Concluding confirmation of the selected set-
ting.
R Return to the previous menu level.
R Exit the menu. Attention: Altered setting is
stored nevertheless.
10.2 Settings menu
1. Press the <MENU> key.
 The first menu level will be called up.
2. Select the "Settings" menu item by navigating
through the options with the aid of the <–> or <+>
key.
3. Press the <MENU> key to confirm.
" The second level of the menus for the settings is
opened.
Item Description
Language selection List of languages available in the system
Screensaver ON = Active
OFF = Deactivated
Audible signal ON = An audible signal sounds during
acquisition of the measured data
OFF = No audible signal sounds during
acquisition of the measured data
Automatic start-up ON = Start of measurement by closing
wheel-guard hood
OFF = Start of measurement by
pressing the <START> key with wheel-
guard hood closed
Unit for balance
weight
g = Display in grams
oz = Display in ounces
Display resolution for
balance weight
1g / 0.05oz - Fine resolution
5g / 0.25oz - Standard resolution
"OSD" program for
optimizing the static
and dynamic wheel
imbalance
ON = Active
OFF = Deactivated
Item Description
Tolerance for display
value "0"
Entry of balance weight value below
which the value "0" is to be displayed.
Standard value: 5g (0.15oz)
Maximum value: 25g (1oz)
Wheelbase value: 0.5g (0.05oz)
Tolerance for display
value of "0" when the
"OSD" program is
activated.
Balance weight input value below which
the display value "0" should appear
when the OSD program is activated.
Standard value: 4g (0.20oz)
Maximum value: 25g (1oz)
Wheelbase value: 0.5g (0.05oz)
4. Make the desired changes.
i Press the <STOP> key to complete.
10.3 Calibration menu
1. Press the <MENU> key.
 The first menu level will be called up.
2. Select the "Calibration" menu item by navigating
through the options with the aid of the <–> or <+>
key.
3. Press the <MENU> key to confirm.
 The user is requested to enter a password.
4. Enter and confirm the password 2857.
" The calibration options are presented.
Item Description
Calibrating the flange Starts the process of calibrating the
flange
Calibrating the rim-
distance gauge/sonar
probe
Starts the process of calibrating the
electronic rim-distance gauge and the
sonar probe
Calibrating the wheel
imbalance
Starts the process of calibrating with
wheel and balance weight
5. Open the desired process.
i The calibration process is described in the
"Calibration" section.
i Press the <STOP> key to complete.
10.4 Statistics menu
1. Press the <MENU> key.
 The first menu level will be called up.
2. Select the "Display statistics" menu item by
navigating through the options with the aid of the
<–> or <+> key.
3. Press the <MENU> key to confirm.
" The usage statistics are opened.
i Press the <STOP> key to complete.
