Symbols used | MT ZERO 6 LCD | 71 en
1.2.1 Safety symbols
Symbols Description Definition M
1
P
2
WARNING
There are devices fit-
ted to the product
that use laser beams!*
Indicates the type and properties of the laser
equipment used on the product and the immediate
risks of exposure.
X X
WARNING
Source of the laser
beam!*
Indicates the positions of the laser devices. X X
DANGER – live parts
when opening the
MT ZERO 6 LCD!
Risk of injury, heart failure or death from electric shock
when touching live parts (e.g. main switch, circuit
boards).
R Work on electrical systems or equipment must only
be performed by qualified electricians or trained
personnel under the guidance and supervision of an
electrician.
R Disconnect the MT ZERO 6 LCD from the mains
voltage system before opening.
X X
* Version with positioning laser only
1
M = MT ZERO 6 LCD AWx
2
P = MT ZERO 6 LCD AWxP
1.2.2 Certification symbols
Symbols Description Definition M
1
P
2
EAC identification Confirms the suitability of the machine for Russia. X X
Type plate Machine model, 10-digit ID number, voltage (V),
frequency (Hz), connected load (kW), amperage (A),
max. supply pressure (kPa), degree of protection
(IP), year of manufacture, CE mark, EAC mark, serial
number of the machine, barcode.
X X
1
M = MT ZERO 6 LCD AWx
2
P = MT ZERO 6 LCD AWxP
