Field Description
dress/Netmask Enter the destination IP address and corresponding netmask to
which the original destination IP address is to be translated.
New Destination Port Only for Type of traffic = %# 5 )3*!,
Service = $ and Protocol = *6, .5, *6/.5
Leave the destination port as it appears or enter the destination
port to which the original destination port is to be translated.
Select -#1 to leave the original destination port. If you
disable -#1, an input field appears and you can enter a
new destination port.
-#1is active by default.
New Source IP Ad-
dress/Netmask
Only for Type of traffic = ## % )3*! and NAT
method = (%
Enter the source IP address to which the original source IP ad-
dress is to be translated, with corresponding netmask, as the
case arises.
New Source Port Only for Type of traffic = ## % )3*!, NAT
method = (%, Service = $ and Pro-
tocol = *6, .5, *6/.5
Leave the source port as it appears or enter a new source port
to which the original source port is to be translated.
-#1 leaves the original source port. If you disable -
#1, an input field appears in which you can enter a new
source port. -#1is active by default.
If you select +%$( + # for Original Source Port/
Range, you can choose from the follwing options:
• . -#1 % /A#: The range specified
for Original Source Port/Range is not changed, all port num-
bers are retained.
• 97 /;% "# ": There is an
input field for you to specify the port number with which to
start the port range that replaces the original port rannge. The
count of ports is retained.
bintec elmeg GmbH
11 Networking
bintec RS Series 217
