LED Colour Status Information
off No connector.
flashing Data traffic via the DSL interface.
WLAN green on The wireless module is active.
off No connector to wireless module.
flashing Data traffic via the WLAN interface.
USB green on USB connection is active.
off No connector.
flashing Data traffic via the USB interface.
3G/4G green on UMTS/LTE connected to the network via the
internal modem after successful dial.
off No connector.
flashing Data traffic via the internal UMTS/LTE mo-
dem.
BRI green on D-channel is active.
off No connector.
flashing At least one B-channel is active.
You can determine the status of the router in BRRP operation with the aid of the status
LED.
LED BRRP display
LED Colour Status Information
STATUS green lights The device is functioning as a master router.
STATUS green off The device is functioning as a backup
router.
STATUS green flashing The device is being initialised.
3.4.5 Scope of supply
Your device is supplied with the following parts:
Scope of supply bintec RS232j bintec RS232jw bintec RS232j-4G
Cable sets/mains unit/
other
Ethernet cable (yellow)
ADSL cable for Annex B
/ J (grey)
Ethernet cable (yellow)
ADSL cable for Annex B
/ J (grey)
Ethernet cable (yellow)
ADSL cable for Annex B
/ J (grey)
