Field Description
works state, switch port 5 is assigned to interface .
Configured Speed /
Mode
Select the mode in which the interface is to run.
Possible values:
• =? "+ / =11 5+1? (default value)
• ): The interface is created but remains inactive.
Current Speed / Mode Shows the actual mode and actual speed of the interface.
Possible values:
• "+ / =11 5+1?
• 57
8.2 ISDN Ports
In this menu, you configure the ISDN interface of your device. Here you enter data such as
the type of ISDN connection to which your device is connected.
You can use the ISDN BRI interface of your device for both dialup and leased lines over
ISDN. Proceed as follows to configure the ISDN BRI interface:
• Enter the settings for your ISDN connection: Here you set the most important parameters
of your ISDN connection.
• MSN Configuration: Here you tell your device how to react to incoming calls from the
WAN.
8.2.1 ISDN Configuration
Note
If the ISDN protocol is not detected, it must be selected manually under Port Usage
und ISDN Configuration Type. The automatic D channel detection is then switched
off. An incorrectly set ISDN protocol prevents ISDN connections being set up.
In the Physical Interfaces->ISDN Ports->ISDN Configuration menu, a list of all ISDN
ports and their configuration are displayed.
8 Physical Interfaces bintec elmeg GmbH
142 bintec RS Series
