Field Description
Transmit Shaping Select whether the data rate in the send direction is to be re-
duced. This is only needed in a few cases for special DSLAMs.
Possible values:
• 5$1 0 +!: The data rate in the send direc-
tion is not reduced.
• "+, "+, "+, "+,
, "+, "+, & "+ and
"+: The data rate in the send direction is reduced to a max-
imum of 128,000 bps to 2,048,000 bps in defined steps.
• . $:The data rate is reduced to the value entered
in Maximum Upstream Bandwidth.
The default value is 5$1 0 +!.
Maximum Upstream
Bandwidth
Only for Transmit Shaping = . $
Enter the maximum data rate in the send direction in bits per
second.
The menu Advanced Settings consists of the following fields:
Fields in the Advanced Settings menu.
Field Description
ADSL Line Profile
Select the internet service provider you require and, in doing so,
implicitly select the modem parameter set used by this provider.
5% *1: is entered as the default value.
If your provider is not shown in the list, use the $1 set-
ting.
8.4 UMTS/LTE
bintec elmeg GmbH
8 Physical Interfaces
bintec RS Series 151
