For alternative configuration options, connect the serial interface of your PC with the seri-
al interface of the device (Console). However, configuration via the serial interface is not
provided by default. A suitable cable is available as an accessory.
The device is now ready for configuration with the GUI. Chapter Basic configuration on
page 50 provides a detailed step-by-step guide to the basic functions on your device.
Installation
The access points can be fitted to the wall using brackets or can used as a table-top
device.
Use as a table-top device
Attach the four self-adhesive feet on the bottom of the device. Place your device on a solid,
level base.
Wallmounting
To attach the devices bintec RS120x to the wall, use the brackets on the back of the hous-
ing.
Warning
Before drilling, make sure that there are no building installations where you are drilling.
If gas, electricity, water or waste water lines are damaged, you may endanger your life
or damage property.
Kensington Lock
The devicesoffer the option to fit a Kensington Lock. The opening required for this can be
found on the right side of the housing.
3.2.2 Connectors
All the connections are located on the back of the device.
bintec RS120 and bintec RS120wu have a 4-port gigabit switch, a gigabit LAN/WAN con-
nector and a serial interface, an SFP LAN connector and a USB connector. bintec
RS120wu has connections for 3 external WLAN antenna as well as for 2 external UMTS
antenna.
