LED Farbe Status Information
WLAN (only
RS353jw)
green on WLAN connection established.
green flashing Data traffic via WLAN send / receive.
off No WLAN connection.
USB green on USB connection established.
green flashing Data traffic via USB send / receive.
off No USB connection.
LTE green on LTE connection established.
green flashing Data tgraffic via LTE send / receive.
off No LTE connection.
BRI green on D-channel is active.
green flashing At least one B-channel is active.
off No ISDN connection.
LAN 1 bis 4:
LINK/ACT
green on Ethernet connection established.
green flashing Data traffic via Ethernet.
off No Ethernet connection.
LAN 1 bis 4:
Speed
green on 1000 Mbits transfer rate.
orange on 100 Mbits transfer rate.
off 10 Mbits transfer rate.
LAN 5: LINK/
ACT
green on WAN-Ethernet connection established.
green flashing Data via LAN 5 send / receive.
off No Ethernet connection.
LAN 5: Speed green on The device is connected to the WAN at
1000 Mbits.
orange on The device is connected to the WAN at 100
Mbits.
off The device is connected to the WAN at 10
Mbits, or no Data transfer.
You can determine the status of the router in BRRP operation with the aid of the status
LED.
bintec elmeg GmbH
3 Installation
bintec RS Series 11
