Fig. 99: Networking->Drop In->Drop In Groups->New
The Networking->Drop In->Drop In Groups->New menu consists of the following fields:
Fields in the Basic Parameters menu.
Field Description
Group Description Enter a unique name for the Drop In group.
Mode Select which mode is to be used to send the MAC addresses of
network components.
Possible values:
• *+ (default value): ARP packets and IP packets
belonging to the drop-in network are routed transparently
(unchanged).
• ?(: ARP packets and IP packets related to the drop-in
network are forwarded with the MAC address of the corres-
ponding interface.
Exclude from NAT
(DMZ)
Here you can take data traffic from NAT.
Use this function to, for example, ensure that certain web serv-
ers in a DMZ can be accessed.
The function is enabled with "1.
bintec elmeg GmbH
11 Networking
bintec RS Series 249
