LED Colour Status Information
Ethernet 1 to
4: SPEED
green on The device is connected to the LAN at 1000
mbps.
orange on The device is connected to the LAN at 100
mbps.
off The device is connected to the LAN at 10
mbps or there is no data traffic.
Ethernet 5:
LINK/ACT
green on The connection to the WAN has been estab-
lished.
green flashing Data traffic via the WAN interface.
off No connector.
Ethernet 5:
SPEED
green on The device is connected to the WAN at
1000 mbps.
orange on The device is connected to the WAN at 100
mbps.
off The device is connected to the LAN at 10
mbps or there is no data traffic.
ADSL green on DSL connection is active.
off No connector.
flashing Data traffic via the DSL interface.
WLAN (only
bintec
RS230aw )
green on The wireless module is active.
off No connector to wireless module.
flashing Data traffic via the WLAN interface.
USB green on USB connection is active.
off No connector.
flashing Data traffic via the USB interface.
UMTS (only
bintec
RS230aw )
green on UMTS/LTE connection is active.
off No connector.
flashing Data traffic over UMTS/LTE.
You can determine the status of the router in BRRP operation with the aid of the status
LED.
bintec elmeg GmbH
3 Installation
bintec RS Series 29
