S10/S12/S10A/S12A Patient Monitor User’s Manual
12-4
12.5. NIBP Display
The NIBP display shows only numerics.
(1) Parameter Label
(2) NIBP Unit: mmHg or kPa
(3) The last NIBP measurement time
(4) Time to the next measurement (for Auto mode and Sequence only).
(5) Measurement mode: The measurement interval time is displayed during
Auto NIBP
measurement, and the current measurement period and measurement interval time are
displayed during Sequence measurement.
(6) Mean pressure alarm limit
(7) Mean pressure (displayed after measurement completed) or cuff pressure (displayed
during the measurement)
(8) Diastolic pressure alarm limit
(9) Diastolic pressure
(10) Systolic pressure
(11) Systolic pressure
alarm limit
NOTE
:
If NIBP measurement fails, "XX" is displayed; if NIBP measurement is not
taken, "--" is displayed
Outlined NIBP numerics indicate that the measurement exceeds the set time.
So these NIBP values are not recommended for reference.
1
4
5
11
3
2
10 9
8
7
6
