S10/S12/S10A/S12A Patient Monitor User’s Manual
8-9

pacemakers. Always keep these patients under close surveillance.
 The auto pacer recognition function is not applicable to pediatric and neonatal
patients.
 For non-paced patients, you must set 【Paced】to 【No】.
8.4.7. Enabling Pacer Rejection
The pace pulse rejection function is disabled by default. To enable this function,
follow this procedure：
1. Select ECG parameter area or waveform area to enter the【ECG】menu.
2. Select【Paced】submenu.
3. Switch on【Pacer Reject】.
NOTE
：
 When pace pulses are detected, the pace pulse marks “|” are shown on the
ECG waveforms. 【Pacer Reject】 setting has no impact on the display of pace
pulse marks “|”.
 You can switch on 【Pacer Reject】 only when 【Paced】 is set to 【Yes】.
8.5. ECG Settings
8.5.1. Selecting ECG Screen
When monitoring ECG, you can choose the screen as desired.
 For 3-lead ECG monitoring, only normal screen is available.
 For 5-lead ECG monitoring, besides the normal screen, it can be selected to
display 7 waveforms.
 For 6-lead ECG monitoring, besides the normal screen, it can be selected to
display 8 waveforms.

For 12-lead ECG monitoring, besides the normal screen, it can be
selected to display 12 waveforms.
