S10/S12/S10A/S12A Patient Monitor User’s Manual
8-10

To choose the screen type, follow this procedure:
1. 【Screen Select】interface in one of the following ways:
 Select【Screen Setup】quick keySelect【Screen Select】submenu.
 Select【Main Menu】quick keyfrom 【Display】 column to select
【Screen Select】.
2. Select【ECG
Screen】.
8.5.2. Setting ECG Alarm
To set ECG alarm properties, follow this procedure:
1. Select the ECGparameter area or waveform area to enter the【ECG】menu.
2. Select【Alarm】submenu.
3. If the alarm settings are password protected, enter the password. For details,
please refer to 7.6.2 Changing Alarm Setup Protection Mode.
4. Set alarms as needed.
8.5.3. Setting ECG calculating Lead
You can set the label name of the ECG calculation lead as follows:
1. Select ECG parameter area or waveform area to enter the【ECG】menu.
2. Select【Setup】submenu.
3. Select【ECG 1】or【ECG 2】 to set label name of ECG calculating Lead.
WARNING：
 Only when you switch on 【Multi-lead Analysis】can you set 【ECG 2】.
8.5.4. Setting Multi-lead Analysis
When multi-lead analysis function is switched on, the【ECG 2】participate in the
calculation of HR, the steps to set up the multi-lead analysis switch are as follows:
1. Select ECG
parameter area or waveform area to enter the【ECG】menu.
2. Select【Setup】submenu.
3. Switch on or off【Multi-lead Analysis】.
