S10/S12/S10A/S12A Patient Monitor User’s Manual
21-1

Chapter 21 Other Functions
21.1. Analog Signal Output
The monitor has an auxiliary output port that can provide “analog signal output”.
Connect the monitor to equipment such as an oscillograph, and then do some associated
setup, after that you can output the analog signal to the oscillograph through the port.
The setting ways of analog signal output are as below:
1. Select 【 Main Menu 】 quick keyfrom 【 System 】 column to select
【Maintenance】input maintenance passwordEnter.
2. Select【Module】submenu【Auxiliary Output】submenu.
3. Select 【Analog Output】, set the analog output signal as required.
CAUTION:
 Analog output function is seldom used in clinic. If you need t know more
detailed information, please contact the service personnel.
21.2. Network Settings
21.2.1. Setting the type of network
The steps for setting the network type are as follows:
1. Select 【 Main Menu 】 quick keyfrom 【 System 】 column to select
【Maintenance】input maintenance passwordEnter.
2. Select 【Network Setup】 submenu  【Network Type】.
3. Set to 【LAN】 or 【WLAN】 according to the network type used.
21.2.2. Setting the Wired Network
To set the wired network, follow this procedure:
1. Select【 Main Menu】 quick keyfrom【 System】 column to select
【Maintenance】input maintenance passwordEnter.
