Biolight Meditech S10 - Alarm Specification

S10/S12/S10A/S12A Patient Monitor User’s Manual
27
A.9 Alarm Specification
If no special instructions are given in the following specifications, the adjustable
range of the alarm limit is the same as the measuring range of the signal.
A.9.1 ECG
Alarm limit Range Step
ST High (low limit +0.01 Mv) ~2.00mV
0.01 mV
ST Low -2.00 mV ~ (high limit -0.01 mV)
HR High (HR low limit +1bpm) ~350bpm
1bpm
HR Low 0bpm~ (HR high limit -1bpm)
QTc High
200ms～700ms
1ms
QTc Low
-500ms～500ms
A.9.2 RESP
Alarm limit Range Step
RR High
(low limit +1 rpm) ～150rpm
1rpm
RR Low 0rpm~ (high limit -1rpm)
A.9.3 NIBP
Alarm limit Range Step
NIBP-S-High
Adult: (low limit+1 mmHg) ~270 mmHg
1mmHg
Pediatric: (low limit+1 mmHg)~235 mmHg
Neonatal: (low limit+1 mmHg) ~135mmHg
NIBP-S-Low 30 mmHg ~ (high limit-1 mmHg)
NIBP-M-High Adult: (low limit+1mmHg) ~235 mmHg
1mmHg
Pediatric: (low limit+1 mmHg) ~225 mmHg
Neonatal: (low limit+1 mmHg) ~125 mmHg
NIBP-M-Low 20 mmHg ~ (high limit-1 mmHg)
NIBP-D-High Adult: (low limit+1mmHg) ~220 mmHg
1mmHg
Pediatric: (low limit+1 mmHg) ~220 mmHg
