S10/S12/S10A/S12A Patient Monitor User’s Manual
26
A.8.8 C.O.
C.O.
Measurement range
0.1 L/min to 20 L/min
Accuracy (simulator)
±5% or ±0.1 L/min, whichever is greater
Resolution
0.1 L/min
TB
Measurement range
23.00°C ~ 43.00°C
Accuracy
±0.1°C
Resolution
0.01°C
TI
Measurement range
-1.0°C ~ 27.0°C
Accuracy
±0.1°C
Resolution
0.1°C
A.8.9 DM
A.8.9.1 Functional Specification
Liquid stop function
Alarm and stop liquid when drip rate is abnormal.
Alarm and stop liquid when infusion is completed.
When the module is powered off, the liquid stop clip is opened
without affecting the infusion.
Unit
Drops/min, mL/h, can be automatically converted (for
conversion, 1mL of conventional tube =20 drops is mainly
used.)
A.8.9.2 Performance Specification
Drip rate
measurement range
5
～
200 Drops/min
（
1mL of conventional tube =20 drops
）
Drip accuracy
±2 and ±2% (whichever is greater)
