S10/S12/S10A/S12A Patient Monitor User’s Manual
3
accessories.
S12/S12A <4kg
175mm * 320mm*
262mm
Including screen, stationary
parameter module, a lithium
battery, a recorder, without
accessories.
A.4 Power Specifications
A.4.1 External power supply
Input voltage
AC (100-240) V(±10%)
Frequency
50Hz/60Hz
Input power
100VA
Standard requirements
According to IEC 60601-1 and IEC 60601-1-2
A.4.2Battery
Battery (Standard configuration)
Type Rechargeable lithium ion battery, 11.1 VDC, 2500mAh
Operating time In a new and fully charged battery at (25℃) ambient temperature,
typical configuration (connected to SpO2; not connected to ECG
and TEMP cable, and NIBP works in an automatic measurement
mode with a time interval of 30 min; Screen brightness is the
factory default value):
S10/S10A: ≥4h
S12/S12A: 4h
Charge time The monitor is charged to 90% for less than 3 hours and 100% for
less than 4 hours when it is turned off.
When the monitor is turned on, it is charged to 90% for less than 5
hours and 100% for less than 6 hours.
Turn off delay
5 min-15min（after the low battery alarm first occurs）
Battery (optional configuration)
Type Rechargeable lithium ion battery, 11.1 VDC, 5000mAh
To Next Page
