S10/S12/S10A/S12A Patient Monitor User’s Manual
17
A.8.4.2 Specification
Measurement parameter
SpO2, PR, PI and RR, SpO2 waveform and respiration
waveform.
Sensitivity
High, Medium, Low
Measurement range and
accuracy
Measurement range 0~100%
Clinical accuracy
70%~100%: 3% (SpO2 probe
included in Appendix);
0~69%: unspecified
Simulator measurement
error*
70%~100%: ±2%
0~69% unspecified
SpO2 Update period
Normal 2s
Maximum 25s
SpO2 Response time
Sensitivity
High 8s
medium 11s
Low 15s
PR
Measurement range 25 bpm ~300 bpm
Resolution 1 bpm
Accuracy ± 3bpm
PI
Measurement range 0.05~20.00%
Resolution 0.01%
Accuracy
0.05~20.00%: ±0.1% or ±10%
of reading, whichever is
greater
RESP (from pleth)
Measurement range 0 rpm ~90 rpm
Resolution 1 rpm
Accuracy ±2 rpm
Sensor model Number of subjects Number of Data Arms
SRA-A11 11 (male 5, female 6) 236 pts 1.67
SRA-A12 11 (male 5, female 6) 236 pts 1.63
SRA-P11 10 (female) 208 pts 2.04
