411829-L, System Settings April 2012 Page 3-12
3
To restore the system configuration e.g. after an update of the system's operating system:
1. Select the Maintenance tab in the right-hand panel.
2. Connect the USB memory device containing the zip file with the desired system configuration to
the USB port located underneath the touch screen. Note that the zip file must be saved at
\biotage\isolera\logs\ on the USB memory device.
3. Press Restore Configuration in the System Configuration and Logs field.
4. In the Select Zip File dialog, select the zip file and press OK. The Restore from USB Device
dialog opens.
5. To confirm restore, press Restore.
6. When the Restore Successful dialog appears, press OK. The Restart Required dialog opens.
7. Read the instructions in the dialog on how to restart the system and then press OK.
8. Restart the system.
9. If you have a USB printer connected to the system, set up the printer as described in “Set Up a
Printer and Auto Print of Reports” on page 3-6.
10. Verify that the calibration of the touch screen and the fraction collector is working properly. If
the system needs to be recalibrated; see “Calibrate the Touch Screen” on page 3-12 and
“Calibrate the Fraction Collector” on page 3-13.
3.7.3 Back Up and Restore the System’s Database
To back up the database:
1. Select the Maintenance tab in the right-hand panel.
2. If you want to save the backup on a USB memory device:
a. Connect a memory device to the USB port located underneath the touch screen.
b. Press Back Up in the Back Up and Restore Database field.
3. If you want to save the backup in the specified share folder, press Back Up in the Back Up
and Restore Database field. The backup file is saved at \biotage\isolera\backup\.
To restore the database:
1. Select the Maintenance tab in the right-hand panel.
2. If the backup file you want to use to restore the database is saved on a USB memory device
(at \biotage\isolera\backup\):
a. Connect the memory device to the USB port located underneath the touch screen.
b. Press Restore in the Back Up and Restore Database field.
3. If the backup is available in the specified share folder (at \biotage\isolera\backup\), press
Restore in the Back Up and Restore Database field.
4. In the Select Backup File dialog, select the backup file and press OK. The Restore from USB
Device/Share Folder dialog opens.
5. To confirm restore, press Restore.
3.7.4 Calibrate the Touch Screen
If the touch screen needs to be recalibrated, use the following procedure.
1. Select the Maintenance tab in the right-hand panel.
2. Press Calibrate in the Touch Screen field. Read and follow the instructions that appear on the screen.
