Instruction manual GSP Maintenance
38107010002 en-US 71 / 92
8.6.3 Attaching the sharpener
WARNING
Unprotected blade!
Coming in contact with the sharp blade can lead to serious injuries.
– Wear cut-proof gloves when cleaning and sharpening.
– Do not clean the blades when operating the machine.
Set slice thickness knob to "24" or open
until stop.
Sharpener marking must be at "0".
Move carriage to relevant position.
Mount sharpener to gauge plate from the
top.
Fig.102: Attaching the sharpener
Push the sharpener and carriage to-
wards the blade until the adapter con-
tacts the front of the blade guard ring.
Keep the sharpener in this position and
use the star knob to screw it to the
gauge plate.
Fig.103: Tighten sharpener
8.6.4 Sharpening
Wear eye protection!
Hearing protection is recommended.
