Operation Instruction manual GSP
46 / 92 38107010002 en-US
For tied product ends to be cut by hand.
Place product end against the rear wall,
making sure that the original cut surface
faces the remnant holder plate.
Position the product fixation device
against the product.
Using handle, swivel in and hold product
holder.
Place product holder behind product.
Switch on machine.
Set slice thickness at knob.
Set stroke width and number of carriage
strokes or change after start.
Fig.48: Load the product
Start carriage motor.
Slices drop on depositing area.
Stop carriage motor.
The carriage runs towards the operator,
the blade is on hold.
Once the slicing process is completed
set slice thickness to "0".
Switch off machine.
Fig.49: Slice product
6.2.3 Manual carriage guide with servo support
The following description applies to all carriage versions, for long product or remnant
pieces:
Application:
– with product that is difficult to slice
– with low number of slices
– thick slices
The servo-motor support comes automatically into action during the manual carriage move-
ment.
The servo support can be adjusted in three steps via <SPEED> keys:
– Level 1 = light support, 1 LED lights up
– Level 2 = medium support, 2 LEDs light up, pre-set as standard
– Level 3 = max. support, 3 LEDs light up
